CFX-102 RGB Multi-Angle LED CO2 Jet Machine
180° Adjustable Jet · 12x3W RGB Illumination · 6-Channel DMX512 Control.
The CFX-102 is a professional-grade 3-in-1 atmospheric effects system that combines high-velocity CO2 fog jets with a brilliant full-spectrum RGB LED array. Designed for high-energy concerts, superclubs, and theatrical stage productions, this machine shoots thick, illuminated columns of freezing fog into the air. Featuring a 180° adjustable output angle and comprehensive 6-channel DMX512 programming, it gives lighting designers complete freedom to create crossing arcs, vertical blasts, or horizontal fog walls. Housed in a heavy-duty, powder-coated iron chassis, the CFX-102 is built to withstand the rigorous demands of global touring and live events.
Key Benefits
- Vibrant RGB Illumination: Twelve high-intensity 3W RGB LEDs surround the nozzle, instantly dyeing the white CO2 fog with up to 16 million brilliant color combinations.
- 180° Dynamic Positioning: The fully adjustable nozzle mechanism boasts a 0 to 180-degree vertical range, allowing you to sweep the blast across the stage or aim it precisely over the crowd.
- Comprehensive DMX Control: Utilize 6 dedicated DMX512 channels for independent control over the fog trigger, LED colors, and strobe effects, ensuring seamless synchronization with your light show.
- Global Touring Ready: An auto-sensing 110V/220V power supply allows this machine to operate flawlessly on any international stage without the need for step-down transformers.
- Rapid Deployment: Includes a premium 6-meter high-pressure resin gas hose equipped with quick-connect fittings for fast, leak-free setups.
Setup & Safety Guide
💡
📌
- Mounting & Angling: Secure the machine to the floor or a lighting truss. Manually adjust the nozzle to your desired angle (0–180°) and lock it tightly into place to handle the recoil.
- Hose Connection: Attach the included 6m high-pressure resin hose to your liquid CO2 tank, then snap the quick-connect fitting onto the machine’s intake.
- Power & DMX: Connect the auto-sensing AC power cord. Link your DMX cables and set your starting address for the 6-channel profile.
- Pressurize: Slowly open the CO2 tank valve. Check all connections to ensure there are no hissing leaks.
- Operation: Use your DMX console to control the LED colors, strobe rate, and CO2 spray trigger. Allow the valve to rest between long bursts to prevent internal freezing.
Technical Specifications
| Power Consumption | 150W |
|---|---|
| Input Voltage | AC 110V / 220V (Auto-Sensing Dual Voltage) |
| LED Configuration | 12 pcs × 3W RGB LEDs (36W Total LED Output) |
| Nozzle Adjustability | 0° to 180° Vertical Range (Manual Lock) |
| Control Protocol | DMX512 (6 Channels: Fog Trigger, LEDs, Strobe) |
| Included Gas Hose | 6m (19.7 ft) High-Pressure Resin Hose |
| Chassis Material | Heavy-Duty Iron with Powder-Coated Finish |
| Safety Certifications | CE, FCC, RoHS |
Package Contents
- ✔️ 1 x CFX-102 RGB CO2 Jet Main Unit
- ✔️ 1 x 6m Professional High-Pressure Gas Hose
- ✔️ 1 x International Power Cord
- ✔️ 1 x DMX Control Cable
- ✔️ 1 x Multi-Language Quick Guide
- *Note: Liquid CO2 Tanks are required and sold separately. An optional Heavy-Duty Flight Case is available (+ $129).
💬 Need to add a flight case or a custom hose length?
Chat with our in-house engineering team to customize your order. We offer exclusive B2B bulk discounts, custom high-pressure hose lengths for complex stage rigging, and optional hard-shell flight cases (+ $129) for touring production companies.
Frequently Asked Questions
Q: What does the 6-channel DMX profile control?
A: The 6-channel profile gives you deep control over the effect. It typically assigns channels to the CO2 trigger valve, master dimmer, Red LEDs, Green LEDs, Blue LEDs, and a variable strobe effect, allowing you to perfectly sync the plume color with your existing light show.
Q: What kind of CO2 tank is required?
A: You must use a Liquid-Siphon CO2 cylinder (often called a dip-tube tank). Standard gas-only tanks will not draw the liquid CO2 required to produce the dense, white cryogenic fog effect.
Q: Can the nozzle angle be adjusted during the show via DMX?
A: No. The 0–180° positioning is a manual adjustment. You set the angle of the nozzle and lock it tightly into place prior to the show, ensuring it stays securely aimed exactly where you want it despite the high-pressure gas recoil.
Q: Is the flight case included in the base price?
A: The base price covers the machine and all necessary cables/hoses safely packed in an export carton. The heavy-duty touring flight case is an optional upgrade available for an additional $129. Please contact us via WhatsApp to add it to your order.
