40Wx10 RGBW 4-In-1 LED Super Beam Wall Washer
10×40W High-Brightness LED · 2° Beam Angle · DMX & RDM Control.
The 40Wx10 Super Beam Wall Washer features 10 pieces of high-brightness 40W RGBW 4-in-1 LEDs, delivering an ultra-narrow 2° beam for sharp, vibrant wash effects. It supports DMX512, RDM remote operation, master-slave, self-propelled, and voice control modes — giving you complete flexibility for stage lighting setups. Perfect for clubs, live concerts, stage shows, or architectural washing, this unit’s air-cooled heat dissipation system ensures stable performance and long service life.
Key Benefits
- Massive Output: 10 × 40W RGBW 4-in-1 LEDs deliver incredible brightness and rich, uniform color mixing.
- Ultra-Sharp Beams: A specialized 2° beam angle produces tight, piercing pillars of light perfect for dramatic aerial effects.
- Dynamic Movement: Features a wide motorized Y-axis tilt travel of up to 230° for sweeping light curtains.
- Advanced Control: Full flexibility with DMX512 (7/13/23/43 CH modes), RDM, Master-Slave, Sound, and Auto modes.
- Robust Construction: Built with a durable steel and plastic housing, ensuring reliable performance for rigorous touring and installations.
- Efficient Cooling: Integrated air-cooled heat dissipation system maintains optimal operating temperatures for long-lasting use.
Setup & Operation Guide
💡
⚠️
- Step 1: Unpack and securely mount the light bar to your truss using standard brackets, or place it on a stable floor surface.
- Step 2: Connect the power cable to a suitable AC100-240V power source.
- Step 3: Connect a DMX cable to the DMX IN port for console control, and daisy-chain to other fixtures using DMX OUT.
- Step 4: Press “MENU” to enter the DMX address setup, use the “UP” and “DOWN” keys to adjust, and press “ENTER” to confirm. Select your preferred channel mode (7/13/23/43 CH).
- Step 5: For standalone operation without a controller, switch to sound-activated or auto (self-propelled) mode via the LED menu.
Technical Specifications
| Power Supply / Max Power | AC 100-240V, 50/60Hz / 500W |
|---|---|
| Lamp Beads | 10 × 40W 4-in-1 RGBW LEDs |
| Beam Angle / Y-Axis Travel | 2° Ultra-Narrow / 0–230° Motorized Tilt |
| Control Protocol / DMX CH | DMX512, RDM, Voice Control, Auto, Master-Slave / 7, 13, 23, or 43 Channels |
| Cooling / Protection Level | Air-Cooled Heat Dissipation System / IP20 (Indoor) |
| Material / Dimensions | Steel Body + Plastic / 110 × 9 × 23 cm |
| Weight | 13.6 kg |
| Packing List | 1 x 40Wx10 Super Beam Wall Washer, 1 x Power Cord, 1 x User Manual |
💬 Need bulk quotes or setup advice?
Chat with our technical team for expert advice on pixel-mapping setups, RDM configuration, and special wholesale pricing.
Frequently Asked Questions
Q: What is RDM and how do I use it?
A: RDM (Remote Device Management) is an enhancement to DMX. It allows you to remotely configure the DMX address and monitor fixture status directly from a compatible lighting console, saving you from having to physically access the fixture once it’s rigged.
Q: Can this be used as a traditional wash light?
A: While it is commonly categorized as a “Wall Washer”, its ultra-narrow 2° beam angle makes it function more like a dynamic moving beam bar. It is best used for piercing aerial effects, light curtains, and linear sweeps rather than soft, wide wall washes.
Q: Can I control each of the 10 LEDs individually?
A: Yes! By utilizing the 43-channel DMX mode, you gain full pixel-mapping control, allowing you to program each of the 10 RGBW LEDs independently for complex chases, gradients, and matrix effects.
Q: Is this fixture weatherproof?
A: No. The light has an IP20 protection rating, meaning it is designed strictly for indoor use and must be kept away from rain, moisture, and extreme humidity.
