40W x 19 Bee Eyes Moving Head Wash Light
Unique Honeycomb Lens · Infinite Rotation · Independent Pixel Control.
The 40W x 19 Bee Eyes Moving Head is an absolute powerhouse designed for top-tier professional stages. Each of its 19 high-power 40W RGBW lamp beads can be controlled independently, giving you precise creative freedom for complex beam and dyeing effects. The front lens features a unique honeycomb design capable of infinite, continuous rotation to produce mesmerizing, dream-like kaleidoscope visuals. Built with intelligent features like an auto-rotating display, automatic scanning position memory, and advanced thermal protection, this 1000W fixture guarantees a breathtaking and reliable performance.
Key Benefits
- Massive 1000W Output: 19 × 40W RGBW 4-in-1 LEDs deliver blindingly bright beams and rich, saturated stage washes.
- Infinite Lens Rotation: The unique honeycomb lens rotates continuously in both directions, creating breathtaking vortex and kaleidoscope effects.
- Full Pixel Mapping: Complete independent control over every single LED bead allows for intricate chases, letters, and custom matrix animations.
- Illusion Side Strip: Features an integrated halo ring made of 74pcs 5050 RGB LEDs for added eye-candy and multi-layered visual depth.
- Smart Calibration: The LCD display automatically rotates 180° when rigged upside down, and the fixture features an automatic scanning position memory to correct accidental bumps.
- Pro Thermal Protection: An advanced fan cooling system continuously monitors the core temperature, automatically adjusting to protect the lifespan of the LEDs.
Setup & Operation Guide
💡
📌
- Step 1: Securely rig the moving head to your truss using heavy-duty clamps and a safety cable. The digital display will automatically flip 180° for easy reading.
- Step 2: Connect the main power cable to an AC100V~240V, 50-60Hz power source (rated for at least 1000W).
- Step 3: Connect a DMX cable for console control. You can select from incredibly detailed channel modes (24/26/38/81/95/100/102 CH) depending on your need for pixel mapping and infinite rotation control.
- Step 4: For quick setups without a console, navigate the LCD menu to activate the Sound-Activated or Master/Slave modes.
- Step 5: During operation, the fixture will actively monitor its temperature. If it detects unsafe heat levels due to blocked vents, it will safely pause operation to protect the diodes.
Technical Specifications
| Voltage / Maximum Power | AC100V ~ 240V 50-60HZ / 1000W |
|---|---|
| Main LED Source | 19 × 40W High Power RGBW 4-in-1 LEDs (50,000h Lifespan) |
| Side Light Strip | 74pcs 0.12W 5050 RGB Illusion side illuminated strip |
| Spot Angle / CTO | 0–60° Linear Zoom / Adjustable 2800K–8500K |
| Control Mode / DMX CH | DMX512, Sound-activated, Master/Slave / 24, 26, 38, 81, 95, 100, or 102 Channels |
| Movement Range | Pan: 540° + 16-bit fine / Tilt: 270° + 16-bit fine |
| Dimmer / Strobe | 0–100% Linear Dimming / 1–25 flashes/second |
| Weight / Dimensions | Net Weight: 17 kg / Package Size: 58 × 55 × 38 cm |
| Packing List | 1 x 40Wx19 Bee Eye Moving Head, 1 x Power Cable, 1 x DMX Cable, 1 x Mounting Bracket Kit, 1 x User Manual |
💬 Need a custom quote or expert DMX setup advice?
Chat with our technical team for guidance on pixel-mapping programming, custom rig layouts, and exclusive bulk B2B pricing.
Frequently Asked Questions
Q: What does “Infinite Rotation” mean for the lens?
A: Unlike standard moving heads where a prism stops after a certain degree of rotation, the entire honeycomb lens assembly on this fixture can spin continuously in either direction. This creates a mesmerizing, never-ending vortex or kaleidoscope effect in mid-air.
Q: Why are there so many DMX channel modes (up to 102 CH)?
A: The higher channel modes (like 95, 100, or 102) unlock full “pixel mapping.” This means your DMX console can control the red, green, blue, and white values of every single one of the 19 LEDs individually, allowing you to create custom shapes, letters, and intricate chase patterns across the face of the light.
Q: What is the “Illusion Side Light Strip”?
A: Around the outer edge of the main lens, there is a built-in halo ring made of 74 dedicated 5050 RGB LEDs. This strip can be controlled separately to add glowing rings or chase effects, adding a rich, multi-layered look to the fixture even when facing the audience directly.
Q: Is this fixture suitable for TV or video recording?
A: Yes! It features high-frequency LED dimming to prevent camera flicker, and it includes a CTO (Color Temperature Orange) channel that allows you to finely tune the white light from a warm 2800K to a cool 8500K to perfectly match your cameras.
